Additional information
| Brand | Ohio Gear Iron Man |
|---|---|
| MPN | WBMQ826-60-D-56 |
| Model | Worm Gear Reducers |
| Output HP | 0.835 |
| Input HP | 1.216 |
| Ratio | 60 to 1 |
| Input RPM | 1750 |
| Input Style | C-Face Quill |
| Reducer Type | Single |
| Size | 56C |
| Output RPM | 29 |
| Dimensions | 11.75 in x 16 in x 12.25 in |
| Shaft Seal Material | Viton |
| Housing material | Cast iron |
| Output Torque | 1805 |
| Reducer Style | Worm – Right Angle |
| Mounting Style | Base |
| Input Diameter | 0.625 in |
| Output Shaft Direction | Double |
| Center distance | 2.63 in |
| Angle | Right Angle |
